Flat Bent Glass Tempering Furnace

The flat tempering part and the bent tempering part of the machine are placed on both sides of the heating furnace. Through different glass conveying directions, the functions of flat tempering and curved tempering can be achieved on one device.

Product Detail

Feature：

1.The flat/bent tempering furnace is a bi-direction machine. The glass can enter from both ends, one end for flat glass, another end for bent glass.
2.With mature bending technology. The bent curve and height is adjustable without mould. There is greatly improved the production efficiency.
3.Able to design the machine as requirement.

Technical parameter：

Model	Max. glass size (mm)	Max. Arc (mm)	Min. Radius (mm)	Thickness (mm)	Output-6mm (batch/s)	Total power (KW)
XD-FBH-1208	1200X800	800	400	4~19	240	450
XD-FBH-1512	1500X1200	1200	550	5~19	240	500
XD-FBH-2015	2000X1500	1500	650	5~19	240	550
XD-FBH-2415	2440X1500	1500	650	5~19	240	750
XD-FBH-2420	2440X2000	2000	850	5~19	240	800
