SHANTOU XINDA PRECISION TECHNOLOGY LIMITED

Professional glass machine manufacturer

Glass tempering furnace

Glass Pot lid tempering furnace

Glass Pot lid tempering furnace

Product Description

Flat & Bended glass Tempering Furnace
It is suitable to produce flat and bend tempered glass for architecture, furniture, home appliances, vehicle etc.
The suitable glass sort including: clear float glass, tinted glass, single side screen printing glass, rolled glass, ultra clear glass, and some series of coated glass.
Application: It can produce flat tempered glass, and bend tempered glass. It is dual direction configuration, by loading glass in different direction, you can get different tempered glass: flat or bend.

Main technical features:
☆ Top installed special heat-proof convection fan; Convection system is with top quality stainless steel, heat-proof and antioxidant, ensure excellent glass quality.
☆ Intelligent operation program, reasonable human-computer interface.
☆ Temperature-control module supply precise and accurate data, fast response.
☆ Superior heating element and insulating material can effectively reduce energy consumption.
☆ Remote diagnosis function can help customers deal with equipment problems quickly.

  • Product Detail

型号Model

PBL-6000

PBL-7200P

BL-8500

玻璃厚度 Glass thickness mm

浮法 2-6 / 格法 3-6

浮法 2-6 / 格法 3-6

浮法 2-6 / 格法 3-6

钢化速度 Tempering speed (Φ120X3mm) Pcs/H

800

900

1000

耗电量 Power (KW/H)

35

42

50

工作压力 Working pressure (Mpa)

0.8

0.8

0.8

尺寸 Size (L*D*H)cm

900X250X220

1230X250X220

1380X250X220

约重量 Weight (Kg)

3800

4200

4800

总功率 Total power (KW)

100

120

140

成型直径 Forming diameter (mm)

100-400

100-400

100-400

产品特点Features

大陶瓷辊 Big ceramic roll

实心小陶瓷 solid ceramic roll

空心小陶瓷 hollow ceramic roll
